Usb long acan laser barcode scanner bar code reader
USB Long Acan laser BARCODE SCANNER BAR CODE READER
Superior keyboard wedge interface NOVELL compatible auto caps lock detection ensures that the data always appears on the computer just the way it is encoded in the bar code
Simple programming from your keyboard or scan bar codes!
Operating temperature:0 C-50 C / 32 F to 122 F
Storage Temperature: -40 C-70 C / -40 F to 158 F
Relative Humidity:5%25 -95%25 ( non condensing )
Shock:1.5mm drop on concrete surface
Ambient light immunity: Immune to direct exposure of normal office and factory, lighting conditions, as well as direct exposure to sunlight
Electrostatic Discharge: Conforms to 15KV air discharge and 8KV of contact discharge
Safety: CORH class 2 Laser product , FCC class A and CE
Current consumption:100mA ( Idle current <40mA )
Voltage Requirement:5VDC 5%25
Scanner Type: Bi directional
Light Source :650-670nm ( Visible )
Scan Rate: 100 scans per second
Resolution:0.10mm ( 4 mile ) PCS0.9
Reading Distance: 2.5 -600mm ( 100%25 UPC / EAN )
Print Contrast : 30%25 minimum reflective difference
Dimensions: L160mm x W65mm x H85mm
Scanning angle: Inclination angle 45 Elevation angle 60
UPC / EAN with Supplementals
Interfaces Supported: Keyboard wedge / RS232 / USB
USB Long scan laser BARCODE SCANNER BAR CODE READER*1
