> 2001 tigerstop cnc auto cross cut saw with 6M infeed
2001 tigerstop cnc auto cross cut saw with 6M infeed
Pneumatically operated upcut saw for soft and hardwoods. Equipped with motor brake system. 2 hand push button operation or fully automatic operation with the Tigerstop pusher. Technical Specification:Model MUK 500Serial number MPS 016731Voltage 415vSawblade diameter 500mmCutting capacity 150x250mm 100x400mmMax depth of cut 150mmMotor power 7.5hpTable height 950mmDust outlet 1x100mm and 1x120mmSuppled with inclined tables at 8 degrees rollers mounted in tables. Tigerstop Version 6.8-Max cutting length of 6000mmOverall length of fence 7400mmFence section 100x100mmVoltage 240v 50hzPower 0.6kw servo drivePositioning speed upto 60 m/minRepeatability 0.1mmPushing weight upto 100kgsFitted with the optional spring buffer pusherAutomatic Tiger machine start InterlockSoftware option with the required 24Volt DC in and output signals to startan existing machine and the automaticpush feed cycle. Includes requiredcables and external connection box.Tiger Link SoftwareDo you use design and cut listingsoftware or Excel? Combine cut lists ordownload multiple cut lists to multipleTigerStop cut list locationssimultaneously. Includes optimising Label Printer and Software packagePrints text or barcodes with text labelsfor your parts. Automatically strips self adhesive labels for easy application toyour finished pieces.
