20' ucl horizontal rail fall arrest protection system
20' UCL Horizontal Rail Fall Arrest Protection System
This fall protection system was used only once for training purposes and has been stored unused since.
The Free-Standing Horizontal Rail Fall-Arrest System combines the simplicity of a horizontal rail and trolley system with a portable support structure to provide reliable fall-protection where it s needed, when it s needed. The Free-Standing Horizontal Rail Fall-Arrest System is ideal for work on or near sensitive equipment, such as aircraft, where physical contact is undesirable. The Free-Standing Horizontal Rail Fall-Arrest System is constructed of lightweight powder coated aluminum and zinc plated steel. This system comes with the optional double-track (for improved worker mobility along the length of the entire rail) and two individual man-rated rail trolleys for anchorage of a Personal Fall-Arrest System (PFAS). The Free-Standing Horizontal Rail Fall-Arrest System is easily moved by hand and can be precisely placed to provide maximum protection.
* Make: UCL Advanced Safety Systems (DBI/SALA)
* Component Model: 17705 (System Model: 8517705)
* Type: Horizontal Rail Fall Arrest Protection System
* Dual 20' Ultra-Lok self retracting lifeline (#3103208)
* Includes operator's manual (for 20216/20215)
Click here to learn more about this item from the local distributor's website.
* Overall Width of the Rail: 20 ft.
* Anchorage Height for the Self-Retracting Lifeline (SRL): 147" to 222"
* Overall Minimum and Maximum Height of Unit: 159" to 234"
* Maximum Recommended Working Height: Up to 162"
* Horizontal Rail Offset: 94"
* Overall Height of the Leg Assemblies: 20"
* Overall Length of the Rail System: 211"
* Overall Outside Width of Rail System: 250"
* Inside Clearance Between Leg Assemblies: 232"
* This fall protection system was used only once for training purposes and has been stored unused since
* This item is located in greater Seattle, WA.
