New 20" swg 60" cc gmc cnc-2060F cnc lathe, fanuc 0I-ma
20" Swg 60" cc GMC CNC-2060F NEW CNC LATHE, Fanuc 0i-Ma
20" Swing 60" Centers GMC CNC-2060F NEW CNC LATHE, Fanuc 0i-Mate, 15 HP, Constant Surface Speed
Model: CNC-2060F SPINDLE BORE: 3-1/8"
Ease-of-use FANUC Oi-mate CNC control
CNC programmable spindle speeds from 30 to 2,650 rpm
CSS-constant surface speeds programming
Large spindle bore 3-1/8 , D1-8
Max. swing over cross slide: 11-3/4"
Max. turning diameter over bed: 13-3/8"
Taper of spindle center: MT #6
Spindle speeds, CNC programmable: 30 2,650 rpm
Max. travel of tailstock quill (manual): 6"
Taper of tailstock quill center: MT #5
Standard 4 Position Power Indexing Turret Toolpost
Max. tool size for auto turret toolpost: 1" x 1"
Max. travel for X axis: 10-1/4"
Coolant pump: 1/8 HP , 220V , 3 phase
Overall Dimensions, LxWxH: 138" x 72" x 92
12 manual 3-jaw chuck with top reversible jaws
Power Indexing Automatic 4-position Turret Toolpost
Manual Handwheel (pulse generators) for both X & Z axis movement
12 wedge-type hydraulic 3-jaw chuck (non thru hole) #D8-312
10 wedge-type hydraulic 3-jaw chuck w/2-1/2 dia. thru hole #D8-310
6 position power indexing automatic vertical turret #turret06
10 manual steady rest with brass tips #SR10
5 manual steady rest with brass tips #SR05
12 4-jaw chuck, D1-8, part #4J12D8
16 4-jaw chuck, D1-8, part #4J16D8
One year service certificate including labor warranty for FANUC CNC
One day on-site training for FANUC oi-Mate CNC control
