Pressure gauge / transmitter, 4-20MA, 1/4" npt, 0-3000P
Pressure Gauge / Transmitter, 4-20mA, 1/4" NPT, 0-3000p
This item is a new ASHCROFT XMTR model X10092.5 Industrial Grade Mechanical Pressure Gauge with a built in transmitter with a 4 to 20 mA output. The combination of the gauge and transmitter yields both local and remote indication of the system pressure. The gauge has a 1/4" NPT (M) connection, and is rated at 0 to 3000 psi, with Asshcroft's Flutterguard vibration dampening.
A technological breakthrough, this mechanical gauge is combined with a transmitter to give the user two instruments in one. Using a patented design, the mechanical movement and readings of the gauge is converted into a electrical signal for remote indication or control. With a gauge and transmitter in one instrument, users will see fewer leak paths and less dead-leg. True Zero pointer indication ensures safety and process control - there is no stop pin to mask false zero readings.The gauge has an accuracy of 1% full-scale.
Media compatibility: any media compatible with 316 stainless steel
Process connection: 1/4" NPT (M)
Electrical connections: 2-ft shielded cable
