6" w 12" l mitsui-seiki msg-200MH surface grinder, 2X d


6" W 12" L Mitsui-Seiki MSG-200MH SURFACE GRINDER, 2X D
6" Width 12" Length Mitsui-Seiki MSG-200MH SURFACE GRINDER, 2X DRO, ROLLER BEARING SLIDES, FINE FE
6" X 12" MITSUI "HIGH-PRECISION" (MADE IN JAPAN)
HAND FEED SURFACE GRINDER w/ROLLER BEARING TABLE
** FINE FEEDS FOR CROSS & VERTICAL AXES (.000050" GRAD.)
** ACU-RITE "QWIK-COUNT" 2-AXES DRO **
MODEL: MSG-200MH S/N: 83083582 NEW: 1983
WIDTH & LENGTH GROUND ........................ 6" X 12"
TABLE TO SPINDLE CENTER ........................... 18"
HEIGHT UNDER 8" WHEEL TO CHUCK SURFACE ............ 11"
LONGITUDINAL TABLE TRAVEL ......................... 15"
CROSS TRAVEL ....................................... 8"
GRINDING WHEEL CAPACITY .............. 8" X 3/4" X 1-1/4"
CROSS FEED PER REV. OF HANDWHEEL
(.001" GRAD.) ................................... 0.100"
VERTICAL FEED PER REV. OF HANDWHEEL
(.0001" GRAD.) ................................. 0.0500"
APPROX. WEIGHT ................................ 1,500 LBS.
APPROX. DIMENSIONS ...................... 58" X 46" X 71"H
"ACU-RITE" 2-AXIS DIGITAL READOUT DISPLAY WITH .0001"
FINE FEED OPTIONS FOR BOTH CROSS & VERTICAL AXES, .000050"
TABLE MOVES ON LINEAR BALL BEARINGS (REMOVABLE)
MOUNTED BETWEEN (3) VEE WAYS & (1) FLAT WAY ...
HARDENED & REPLACEABLE STEEL WAYS ON TABLE,
CROSS FEED HANDWHEEL (.0001" VERNIER)
PRECISION CARTRIDGE SPINDLE DESIGN
6" X 12" "O.S. WALKER" FINE-DIVISION PERMANENT MAGNETIC
MACHINE IS WIRED FOR 3/60/220 VOLT ELECTRICS
** INSPECT UNDER POWER OUR HARRISON, NJ WAREHOUSE **
** ORIGINAL PAINT; EXCELLENT CONDITION & APPEARANCE **
