New tsubbaki emerson 20MM x 62MM cam clutch, LD06 ld-06
New in the Box Tsubbaki Emerson Cam Clutch
20mm Inside Diameter, 62mm Outside Diameter and 24mm Wide
19.6 n/M (173 inch/lbs) Maximum Torque
Plate (washer) not included. The recommended size of plate is 20mm bore, 52mm outside diameter by 3mm thick
The following is infomation is from manufacturer;
1. LD Series Cam Clutch is pre-lubricated with special grease and are ready for use. No additional lubricant is required.
2. When installing the clutch on the shaft, press the clutch inner race slightly with a soft hammer to prevent the clutch outer race from slipping away from the inner race.
3. Be sure to attach the plate. This prevents the outer race from slipping away from the inner
race. See recommended dimensions of the plate listed on the right.
4. For lubrication, coat the plate and thrust plate with grease.
5. Never apply thrust loads to the clutch. Other devices should be provided to take up thrust loads applied to the clutch.
6. Key should be in accordance with JIS B1301-1959.
7. The bores of the pulley, sprocket, etc., should have a tolerance of H6 or H7
