Stainless steel disconnect enclosure w/ ab cutout
Stainless Steel Disconnect Enclosure with Clamps, Type 4X
This enclosure features clamps on three sides to keep liquids and contaminants from entering.
These boxes were ordered for a job where the gentleman decided he needed 316L stainless for his application, so his loss will be your gain. The best distributor sales price I could find is $2,437.50, so you can see this is your lucky day!
Enclosures having the preferred cutout are sized for use with up to 200A disconnect switches and up to 400A circuit breakers unless
otherwise specified. Box for disconnect applications in which a clamp-secured door is preferred, this enclosure features clamps on three sides to keep liquids and contaminants from entering and a preferred cutout that accepts major brand disconnect switches and circuit breakers.
14 gauge Type 304 stainless steel
Seams continuously welded and ground smooth
External-formed flange around all sides of enclosure opening
Stainless steel door clamps on three sides of door
Door removed by pulling stainless steel continuous hinge pin
Data pocket is high-impact thermoplastic
Seamless foam-in-place gasket
Collar studs provided for mounting optional panels
Holes provided in body for mounting disconnect operating handle and operating mechanism
Bonding provision on door; ground stud on body
All exterior hardware on Type 316L enclosures matches the enclosure material
Bracket welded to door to attach disconnect door catch (interlock)
Includes instructions for installing disconnect switches, circuit breakers and operating mechanisms
The preferred cutout accepts the smaller operating handle whose mounting hole centers are 4.688 in. apart. Preferred cutouts are standard in mild steel wall-mount enclosures, modular enclosures and some select large mild steel enclosures. They are also present on all standard stainless steel offerings. Mild steel operator adapter plates with brand specific preferred cutouts are available for enclosures with a rectangular universal cutout.
Preferred cutouts are designed to house the following:
Bulletin 1494V disconnect switches with flange-mount variable depth operating mechanisms and Bulletin 1494V flange-mount
variable-depth operating mechanisms for circuit breakers
Bulletin 140U flexible cable operating mechanisms for 140U molded case circuit breakers
Bulletin 1494C cable-operated disconnect switches with flange mount handles
Bulletin 194RC cable-operated flange-mount handles for use with the NFPA 79 compliant 194R IEC rotary disconnect switches
Allen-Bradley Bulletin 1494V-R1, -R2 and -W2 operating handles and Allen-Bradley Bulletin 1494F disconnect devices or Bulletin 1494D circuit breaker operators will NOT fit these enclosures.
ABB Controls flange-mount variable-depth operating mechanisms for disconnect switches and circuit breakers. Also the cable version
Eaton Cutler-Hammer Type C361 flange-mount variable-depth operating mechanisms with disconnect switches and Type C371
flange-mount variable-depth operating mechanisms for circuit breakers.
General Electric Type STDA flange handles and variable-depth operating mechanisms for disconnect switches and circuit breakers.
Also SPECTRAFLEX cable operators for circuit breakers.
Siemens ITE MAX FLEX flange-mount variable-depth operating handles for circuit breakers.
Schneider Square D Class 9422 disconnect switches with flange mount variable-depth operating mechanisms or cable mechanisms
and Class 9422 flange-mount variable-depth operating mechanisms or cable mechanisms for circuit breakers.
These enclosures will NOT accept Square D Class 9422 bracket-mounted disconnect devices, Class 9422TG1 or TG2 devices.
Warranty: Guaranteed to be as presented and all items guaranteed to be operational upon arrival unless otherwise specified in listing. We pay the return freight for warranty returns. An RMA must be issued before return or a refund will not be. A refund will be issued with return of the original item. Refunds are not issued for any other reason. Our liability will not extend beyond the original purchase price of any item. Any item modified or tampered with is not eligible for return.
