DMX100 full color control rgb led controller+remote 12V
wireless 30 modes DMX100 LED controller With remote control - full-color LED control
DMX100 is a full-color LED control system which uses on indoor and outdoor decorative lighting.This control system can fulfill 256 grey levels for each R,G,B color,totally 16.77 million real full-color. With the wireless remote controller, you can achieve the mode change and speed adjustment very conveniently.There are 30 modes and 8 levels of speed you can choose, and with the pause function,you can keep the fixed color optionally.
* Wireless remote controller
* 256 levels of grey, totally 16.77 million colors, really full color
* Various modes with Pause function
* Eight different speed level
* Automatic parameter memory
* Various output interface, XLR-3 Male & Female, RJ11
* Convenient for wiring and installation
* Input Voltage: 12VDC Include 220/110VAC to 12VDC adaptor
* Transmission interface: DMX512/1990
* Transmition speed: 250Kbps
* Pixels: 50 pixels 170 pixels max.
* Lamp type can be controlled:Wallwashing light, Tube light, Cube light,Underground.
* Control mode:Asynchronous full-color control
* Description:Fixed 30 modes, ,such as flash, fade,streamy,chase, etc.
DMX100 Back Panel Instruction:
* XLR-3 Male output interface
* XLR-3 Female output interface
DMX100 Output Interface Instruction:
A-Mode: Change mode by pressing this button
B-Pause:Keep the fixed color by pressing this button Press it again to continue changing
C-Speed+:Speed up by pressing this button (default: Fastest speed level 1)
D-Speed-:Speed down by pressing this button
Mode 16: Six color fade ( single color fade-over each time)
Mode 17: Red, green & blue fade ( single color fade-over each time)
Mode 18: Red & green fade ( single color fade-over each time)
Mode 19: Red & blue fade ( single color fade-over each time)
Mode 20: Gree & Blue fade ( single color fade-over each time)
Mode 21: Red single color fade
Mode 22: Greed single color fade
Mode 23: Bule single color fade
Mode 24: Seven color jumping changing
Mode 25: Six color jumping changing
Mode 26: R, G, B three color jumping changing
Mode 27: Red & green two color jumping changing
Mode 28: Red & blue two color jumping changing
Mode 29: Green & blue two color jumping changing
Mode15: white single color fade-over
Mode 30: white jumping changing( dark to bright)
1 x DMX100 full-color LED controller
