Hydraulic two pump hi-low unloading valve 1/2" bsp
Hydraulic Two Pump Hi-Low Unloading Valve 1/2" bsp
HYDRAULIC TWO PUMP HI-LOW UNLOADING VALVE 1/2"
This valve is used in a 2 parrallel working pumps circuit in order to release the excess of the higher flow pump to the tank when this gets the required pressure setting. Since this moment and on, the actuator works with the lower flow pump at higher pressure, consuming less energy.
applications: Connect BP to the higher flow pump, AP to the lower flow pump, T to the tank, M to the eventual manometer and U as for necessity.
* Max flow AP 25 l/min , BP 45 l/min, T 65 l/min
