Square d QO330L200G circuit breaker load center 200A
CIRCUIT BREAKER LOAD CENTER 200A/3-PHASE
CIRCUIT BREAKER LOAD CENTER,VOLTAGE RATING:208Y/120VAC-240/120VAC DELTA-240VAC DELTA,AMP:200,PHASE:3,SHORT CIRCUIT CURRENT RATING:65KA,MAIN TYPE:FIXED-FACTORY INSTALLED MAIN LUGS,MAXIMUM SINGLE POLE CIRCUITS:30,SPACES:30,MAXIMUM TANDEM CIRCUIT BREAKERS:0,COVER NOT INCLUDED,WIRE SIZE:#6 TO 250 AWG/KCMIL(AL/CU),WIRING CONFIGURATION:3 OR 4-WIRE,BUS MATERIAL:TIN PLATED ALUMINUM,ENCLOSURE TYPE:INDOOR,BOX NUMBER:9,GROUND BAR INCLUDED,WEIGHT:16 LB/6 OZ,DIMS: 29-7/8"H X 14-1/4"W X 3-5/8"D.
