Sony dkc-5000 digital photo camera w/ leica dm mount
SONY DKC-5000 DIGITAL PHOTO CAMERA W/ LEICA DM MOUNT
Here is a Good Working SONY DKC-5000 CATSEYE DIGITAL STILL CAMERA with Controller/Digitizer and Remote Control, just in from local University surplus. Includes the DKC-5000 Controller with Connection Cable, and a LEICA DM Microscope Mount included (Model T45S made by Diagnostic Instruments), though other lenses and scope mounts could be installed.. The camera can utilize interchangeable lenses (1/2 inch, 38mm bayonet). Comes with Power Cord, and otherwise as pictured.
The DKC-5000 CatsEye Digital camera performs real time full color image capture.Captured images are stored in internal memory where they can be previewed.It has two frame memories, with up to eight additional frame memories offered as an option.The images can be transferred to a computer in about 20 seconds, or, in a stand alone system, printed directly to a digital color printer.The CatsEye digital camera has the flexibility to satisfy the requirements of a wide range of applications including:prepress, computer graphics, instant portraiture, scientific imaging, analysis and microscopy, and industrial imaging.Key features include:high performance 3 CCD camera head, high resolution digital image, 10 bit A/D conversion, adjustable gamma, strobe synchronization, up to 10 internal frame memory, SCSI interface, interchangeable lenses (1/2 inch, 38mm bayonet), variable speed electronic shutter, and photo proofing function. Features: 3CCD 1/2 Bayonet Mount, Live preview for focus and iris adjustment, Long Exposure (4 seconds), Memory: Standard 2 images, Image Size: 1544 x 1120 x3 (5.2MB), Variable speed electronic shutter, Supports Macintosh and IBM-PC. Preview function requires an optional RGB monitor that supports PAL format, i.e. PVM-1954Q.
Produces high resolution images with remarkable color fidelity in real-time
Three 1/2" CCD chips, totaling 1.3 million pixels
Stores up to 10 images in memory for faster throughput
Can capture 10 shots simultaneously
Preview images on the monitor and then print or transfer to a computer
Shoot in tungsten or strobe lighting conditions
Adjust zoom, focus and aperture manually or by remote control
Set color and tonal range directly from the camera
Supports standard hardware platform and software programs
Supplied with Adobe PhotoshopTM plug-in module for PC or Mac
Ideal for portraits, advertisements, catalogs, inserts, brochures or mailers - the applications are limitless
The DKC-5000 was engineered for fast image capture, high resolution and exceptional color accuracy.
Three 1/2" CCD chips, totaling 1.3 million pixels capture red, green and blue separately and simultaneously for a superior level of color interpretation.
Shooting action shots? Fire away. The CatsEye camera stores up to 10 images in memory. That means you get faster through-put and have the power to capture 10 shots simultaneously.
The CatsEye is amazingly flexible. Shoot in tungsten or strobe lighting conditions. Adjust zoom, focus and aperture manually or by remote control. Set color and tonal range from the camera.
The CatsEye supports standard hardware platforms and software programs. Which means, it's graphic intuitive and very easy to use. With its supplied Adobe Photoshop plug-in module, images can be captured and manipulated right from a computer.
Image Size: 1520 x 1144 x 3 (5.2 MB)
Imaging Element: 1/2 inch, 440,000-pixel CCD x 3795H x 598V x 3 RGB x 8 bits/pixelsVertical and Horizontal Pixel Offset
Quantification Table: 10-bits/color, RGB
Memory: Standard 2 ImagesExpansion Memory (DKB-5008)Additional 8 images
External Interface: SCSI/SCSI-2, Amphenol 50-pin x 2
Lens Mount: 1/2 inch 38 Bayonet Mount
Signal-to-Noise Ratio: 56 dB or better
ISO Speeds: AUTO, 100,200,400, 800 (equivalent)
White Balance: AUTO (FLASH ON/OFF)MANUAL(R,B GAIN, -127 to +127)
Electronic Shutter: Auto, 4 seconds to 1/10,000
Settings: Gamma: Printer, ON, OFF, USER1, USER2, USER3,Output LUT All 8-bit RGB
Controls: Contrast, Red, Blue Controls, -127 to +127LUT (Color Look-Up Tables) for optimum color calibrationAutomatic Black and White BalanceSharpness Controls, None, Low, Medium, High
Flash Timing: X Contact (terminal voltage 400V or less)
PC IN Connector: Stereo mini-jack
TRIG Connector: Stereo mini-jack
REMOTE1: 12-pin multi-connector
Power Supply Voltage: Camera 12V DC, Digitizer 120V (50-60Hz)
Current Consumption: Camera 5.0W, Digitizer 1.0A
Ambient Temperature: Operating 41 to 95 F (5 to 35 C)Storage -4 to 140 F (-20 to 60 )
Remote Control Unit Connector: 4-pin
Viewfinder connector: 8-pin DIN connector
Dimensions: Camera 2.8(W) x 2.8(H) x 4.9(D)inches(70 x 72 x123.5mm)Digitizer 16.7(W) x 14.4(D) x 4.2(H) inches(424 x 356.5 x 105.5mm)
Weight: Camera approximately 1.4 lbs (620 grams)Digitizer approximately 19.9 lbs. (9 kg)
