Linde ucc 305 power supply welder
Linde UCC 305 Power Supply Welder
* Input Voltage 208 / 230 / 460
* Load drawn (input amperage) 94 / 90 / 47
* 60 % duty cycle at 300 amps
* Selectable high frequency
* AC arc stabilizer (infinitely adjustable)
* 3 heat ranges, along with a fine adjustment knob
* LOW AC 2 - 55 amps, DC 2 - 50 amps
* MED AC 7 - 230 amps, DC 7 - 210 amps
* HIGH AC 25 - 380 amps, DC 25 - 300 amps
* Adjustable postflow timer, 0-30 seconds
* Soft start (selectable either on or off)
* Remote contactor (both currently would be activated via foot pedal unless you were using a stick electrode)
* Linde FC-4 foot pedal and brake pedal
* Linde HW1-8 torch with leads
* Long power input cord 25'
* Cart with wheels and spring loaded handle
* Victor argon regulator and tank pressure gauge
* Physical size (machine) 31 wide x 42 deep x 36" high
* Physical size (cart) 31" x 58" x 11"
* Weight: 965 lbs. approximately
Although Linde no longer supports this model, nearly everything in it can
be replaced with regular generic industrial parts.
* Location: Paramount, CA 90723
Please contact us for details at (***) 602-1207.
