Hid vertx V1000 reader interface central station 1000
HID VertX V1000 Reader Interface Central Station 1000
SearchBy9 - 11251 | Location: AK2 | By: Daren | Tester: chino | Quan: 14 | List: 14 | Duplicate? False | Plan: D
Standard Relist: True | Size: 0x0x0 Weight: 5 | MGR: Cameron | Start: $0.00 | BIN: $99.99 | Type: Fixed Price
* HID VertX V1000 Door/Reader Interface CS Central
Datasheet: http:// /documents/vertx_v1000_ds_en.pdf
Installation Guide: http:// /documents/vertx_v1000_ins_en.pdf
The HID VertX products provide a complete and fully featured hardware/firmware infrastructure for OEM access control software host systems, communicating via industry standard TCP/IP protocol, over 10/100 Mbps Ethernet or the Internet. The
V1000 boasts a 32-bit RISC processor running the Linux Operating System. On-board flash memory allows program updates to be downloaded via the network. The V1000 connects up to 32 Door/Reader, Input Monitor, or Output Control Interfaces via two
-Stores a complete access control and configuration database for up to 32 Reader Interfaces (up to 64 doors) and 44,000 cardholders with expansion capability up to 250,000 cardholders.
-The access control system interfaces with combinations of devices with a maximum of:
* 32 Door/Reader interfaces (up to 64 doors/readers) or
* 32 input monitor interfaces 9 (up to 512 monitor points) or
* 32 output control interfaces (up to 384 control relays)
-Reports supervised inputs/alarms with 255 priorities.
Includes an HTTP API, Windows DLL API, and direct communication API.
-Allows local connection of a laptop computer for diagnostics and configuration.
-Connects to the host and other devices on a TCP/IP network.
-Receives and processes real time commands from the host software application.
-Reports all activity to the host.
-Controls and communicates with all connected devices.
-Allows fallback communications via dialup or RF modem if TCP/IP network communication is lost.
-UL 294 and UL 1076 recognized component.
