SIEMENS 760 VALVE CONTROLLER POSITIONER FAIL-SAFE UNIT
Siemens Series 760 Valve Positioner Fail-Safe Positions Valve Controller
The Series 760 Valve Positioners provide a cost effective universal approach to your valve control. Their modular concept allows all models to be built on the base pneumatic unit (Model 760P). The electro-pneumatic model (Model 760E) is created by adding an I/P transducer to the base pneumatic unit, and a wide range of accessories easily installs inside the unit.
The 760 base pneumatic unit provides cam characterization, split ranging, direct or reverse action, and single or double acting without requiring additional parts. Key design features include non-interaction of the zero and span adjustments.
760P: 40 to 185 F ( 40 to 85 C)
High temp. option available to 300 F (148 C)
760E: 40 to 167 F ( 40 to 75 C)
Electrical 3/4" NPT, 25mm
Epoxy/Polyester Powder Coat
Standard Spool: 0.5 scfm typical
High Flow Capacity Spool: 1.0 scfm (typical)
Flow Capacity (at 60 psi with 25% drop)
9.0 scfm (Cv = 0.3) Standard
18.0 scfm (Cv = 0.6) Optional
760P: 3-15 psig, 3-27 psig, 50% split range
760E: 4-20 mA, 50% split range
1/2" to 6" linear optional (longer lengths available on request)
Equal %; Quick Opening; Linear
Adjustable 60% to +25% of normal span
Adjustable 10% to +60% of normal span
Performance Specifications
760P: 0.5% of normal span (typical)
760E: 0.75% of normal span (typical)
760P: 0.75% of normal span (typical)
760E: 1.0% of normal span (typical)
Less than or equal to 0.25% of span
Less than 0.2% of span for a 5 psi change in
Hazardous Area Class Approval
Series 760 Approvals & Certifications
When installed in accordance with Siemens drawing
EN50081-1 and EN50081-2 Emission
EN61000-6-1 and EN60000-6-2 Immunity
See ATEX Certificates for Service Restrictions
Type 4X, in accordance with NEMA Std. 250
Type IP65, in accordance with IEC Std. 529
