TELEPHONE OPERATION CONTROL PANEL
CPP Handset Communication Option
The Bogen CPP Handset Communication Option provides
for control center-to-classroom and classroom-toclassroom
phone communications. The option uses the
Bogen Model TPS4 Control Panel and Bogen HS20-Series
1C or HS202C). The TPS4 panel provides
an on/off switch which disconnects the normal intercom
function of the Bogen Model MCP35A; a call button to
transmit a call tone to the selected speaker; an in-use
LED; and a disconnect function which lights an LED and
sounds a tone to remind the operator to reset the control
panel once classroom-to-classroom communication
Architect and Engineer Specifications
The Bogen CPP Handset Communication Option shall be provided. It shall consist of the Bogen Model TPS4
Control Panel, the Bogen HS20-Series handset(s), and Bogen Model PCMPS2 power supply. The control panel
shall be rack-mountable and shall interconnect with the Bogen Model MCP35A Master Control Panel and room
selector panel(s). The TPS4 shall provide an on/off switch to disconnect the intercom function of the MCP35A,
a call button to activate a call tone at the selected speaker, an in-use LED, and a disconnect function which shall
alert the operator when communication is completed.
